i12 IP Intercom | IP65 IK10 SIP Door Intercom for Access Control
Aluminum alloy front plate, cast aluminum back plate, 2 SIP lines, PoE/DC power supply, built-in tamper-proof detector, and high compatibility with major SIP platforms.
IK10 Protection
CE / FCC
2 SIP Lines
Application
Security Intercom / Access Control
Power
10–14V DC or PoE
Network
10/100 Mbps Ethernet
Installation
Wall-mount
Key Purchase Information
Product Name
i12 IP Intercom
Model
DJS-i12
Main Material
Aluminum alloy + cast aluminum
Protection Level
IP65 / IK10
SIP Lines
2 SIP lines
Power Supply
10–14V/1.5A DC or PoE
Certificates
IP65, IK10, CE, FCC
Compatibility
Asterisk, BroadSoft, 3CX, Avaya etc.
Product Overview
The i12 IP Intercom is designed for outdoor entrance communication, building access control, security linkage, and SIP-based intercom systems. Its aluminum alloy front plate and cast aluminum back plate help provide waterproof, dustproof, anti-impact, and tamper-resistant performance for demanding installation environments. The unit supports one-key or two-key call modes, HD voice, 2 SIP lines, multicast, wall-mount installation, short-circuit input/output linkage, active speaker output, and audio record output. With compatibility across major SIP platforms including Asterisk, BroadSoft, 3CX, Metaswitch, Elastix, and Avaya, it is suitable for distributors, system integrators, building contractors, and project-based security deployments.
Key Features
✓ One-key / Two-key Mode
Flexible call key configuration for different entrance and help-point scenarios.
✓ Security Linkage I/O
2 inputs and 2 outputs for door sensors, emergency buttons, locks, alarm lamps, and other devices.
✓ HD Voice Support
Wideband G.722 codec, acoustic echo cancellation, and hands-free duplex intercom.
✓ Voice Record Output
Audio record output interface supports connection with hard disk video recording systems.
✓ Built-in Tamper Detection
Built-in tamper-proof detector helps prevent external damage and unauthorized removal.
✓ Major Platform Compatibility
Compatible with Asterisk, BroadSoft, 3CX, Metaswitch, Elastix, Avaya, and other SIP systems.
Applications
✓ Apartment entrance intercom
✓ Office building access control
✓ Security help points
✓ Industrial facility communication
✓ Parking lot entrance systems
✓ Campus and public-area intercom
Specifications
| SIP Lines | 2 SIP lines |
| Call Features | Intercom, speed dial, auto-answering per line, voice message on server, local 3-way conference |
| DSS Keys | 1 or 2 DSS keys / intelligent speed dial keys |
| Audio Codec | G.711a/u, G.723.1, G.726-32K, G.729AB, G.722 wideband |
| Audio Processing | AEC, VAD, CNG, BNE, PLC, adaptive jitter buffer up to 300ms |
| DTMF | In-band, Out-of-band DTMF-Relay RFC2833, SIP INFO |
| Pickup Distance | Omnidirectional pickup, maximum up to 5 meters |
| Network | 10/100 Mbps Ethernet, Static/DHCP/PPPoE, 802.1x, VPN, VLAN, QoS |
| Protocols | SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, LLDP, PPPoE, L2TP, OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, TR-069 |
| Deployment | Auto-provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069, web management portal, packet dump, firmware upgrade, syslog |
| Interfaces | RJ45 Ethernet x2, active speaker output, audio record output, 2 short-circuit inputs, 2 short-circuit outputs |
| Power Supply | 10–14V/1.5A DC or PoE |
| Power Consumption | Adapter: 1.08–2.76W; PoE: 1.43–3.52W |
| Material | Front plate: aluminum alloy; back plate: cast aluminum |
| Protection | IP65 and IK10 |
| Working Temperature | -40°C to 70°C |
| Working Humidity | 10%–90% |
| Dimensions | 195 × 120 × 39 mm (W × H × L) |
| Package | 260 × 165 × 62 mm; 10 pcs/CTN; CTN 348 × 328 × 280 mm |
OEM / ODM Customization
Logo & Nameplate
Support customized logo, label, model naming, and brand identification for project supply.
Firmware Configuration
SIP account, network parameters, DSS key behavior, provisioning, and platform settings can be pre-configured.
Packaging Design
Neutral packaging, project packaging, barcode label, and accessory package options are available.
System Integration Support
Support for SIP platforms, access control linkage, remote commands, DTMF control, and output-input linkage.
Certifications
✓ IK10 Anti-impact
✓ CE Certification
✓ FCC Certification
Case Studies
Apartment Entrance Upgrade
Used for multi-tenant building entrance communication with SIP platform integration and remote management.
Industrial Security Point
Installed in outdoor industrial areas requiring waterproof, anti-impact, and emergency communication functions.
Office Access Control Project
Connected with door locks, alarm lamps, and monitoring systems through input/output linkage.
Customer Feedback
★★★★★
“Stable SIP compatibility and strong housing design. The product is suitable for outdoor project installation.”
★★★★★
“Good technical support for provisioning, SIP account setup, and access control linkage testing.”
Procurement Guide
✓ Confirm SIP platform compatibility before bulk order.
✓ Verify required protection level for indoor or outdoor installation.
✓ Check power supply type: DC adapter or PoE deployment.
✓ Prepare SIP account, provisioning, and network configuration details.
✓ Confirm I/O linkage requirements for locks, sensors, alarms, and emergency buttons.
✓ Request product datasheet, installation manual, and certification files before procurement.
Shipping & Trade Terms
Trade Terms
FOB / CIF / EXW / DDP
Express
DHL / FedEx / UPS
Sea Freight
LCL / FCL
Forwarder
Customer-appointed accepted
After-Sales Support
Warranty
Standard project warranty support available.
Technical Documents
Datasheet, installation manual, configuration guide, and API/integration documents.
Remote Support
Support for SIP setup, provisioning, linkage testing, and troubleshooting.
Replacement
Replacement support is available according to project and warranty terms.
Why Choose Us
✓ Industrial intercom manufacturing experience
✓ SIP platform integration support
✓ OEM / ODM configuration available
✓ IP65 / IK10 outdoor-ready design
✓ Project-based technical documentation
✓ Support for bulk deployment and maintenance
FAQ
Q: Does the i12 IP Intercom support SIP?
A: Yes. It supports SIP 2.0 over UDP/TCP/TLS and is compatible with major SIP platforms.
Q: Can it be installed outdoors?
A: Yes. The product has IP65 and IK10 protection and works from -40°C to 70°C.
Q: What power supply does it use?
A: It supports 10–14V/1.5A DC power supply or PoE power supply.
Q: Does it support linkage with external devices?
A: Yes. It includes 2 embedded input interfaces and 2 output interfaces for locks, sensors, alarm lamps, and emergency devices.
Q: Can firmware be upgraded?
A: Yes. It supports firmware upgrade, auto-provisioning, configuration import/export, and web management.
Q: Is OEM customization available?
A: Yes. Logo, packaging, firmware configuration, and project settings can be discussed based on order quantity.
Need i12 IP Intercom for Your Project?
Send your project quantity, SIP platform, installation environment, power supply type, and customization requirements. Our team will provide quotation, datasheet, and technical support.
